Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in making in manufacturing construction equipment. machinery such as aerial lifts, manlifts and boom lifts. These equipments are designed to facilitate access to difficult to reach areas, roofs and buildings, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes steps or handholds or paltforms that are connected to the unit to be able to transport employees from each floor.
TB85
The TB85 man lift by Terex provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is approximately 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
